1. Maximum Capacity in the Jumbo Range Fifteen seamless steel cylinders integrated into a standard 40ft frame deliver a total water capacity of 36.75 m³ with up to 11,573 Nm³ of CNG per unit—one of the highest payload configuration in the SinoCleansky Jumbo series.
2. High-Pressure Design with Generous Safety Margin Working pressure of 25 MPa, hydrostatic test pressure of 37.5 MPa (1.5× safety factor), equipped with bursting disc devices and comprehensive pressure relief systems for safe operation under extreme conditions.
3. Fully Compliant with International Standards Cylinders manufactured to ISO 11120:2015; container frame meets ISO 668, ISO 6346 & ISO 1496-3 freight container standards, enabling seamless intermodal transport via road, rail, and sea.
4. Fully Seamless Hot-Extruded Cylinders — Zero Welding 4142 material steel cylinders are produced by hot extrusion process with no weld seams on the cylinder body, eliminating welding stress concentration risks and delivering superior fatigue life.
5. Nitrogen-Purged and Ready for Immediate Use After assembly, the interior is nitrogen-purged to oxygen content ≤3%, maintained at 0.05–0.1 MPa positive pressure upon delivery to prevent ingress of air and moisture—ready for direct filling upon receipt
SCS15-2450-CNG-25:
Model No. | SCS15-2450-CNG-25 |
Cylinder quantity | 15 |
Filling medium | CNG |
Steel type | 4142 |
Working Pressure | 25Mpa |
Cylinder Water Capacity | 2450L |
Cylinder size/mm | φ559*11580 |
Working temperature | -50℃~65℃ |
Equipment weight/kg | 42,700 |
Filling weight/kg | 8,265 |
Total weight/kg | 50,965 |
Water volume/M³ | 36.75 |
Filling gas volume/Nm³ | 11,573 |
Skid dimension | 12192*2438*2591 |
Suitable for He, AR, N2, Air and other industrial gas, the filling capacity will vary depending on the type of medium.
